Product Specification

• Power Operating Voltage: 21~30V DC, provided by the bus.

• Output Specifications:

  • Number of Outputs: 4
  • Unrated Voltage: 250V/440V AC (50~60Hz)
  • Output Switch Current:
    • Meets AC1 (EN60947-4-1) standards (resistive load).
    • Meets AC3 (EN60947-4-1) standards (capacitive load).
    • Meets EN60669 fluorescent lamp load standards.

• Connection Details:

  • EIB/KNX connection.
  • Load output connection via bus connection terminal (diameter: 0.8mm).
  • Screw terminal connections for load output.

• Cable Cross Section:

  • Single core: 0.2–6.0mm².
  • Multi-core: 0.2–4.0mm².

• Operational Instructions:

  • Contact Position Indication:

Contact Closed → Channel Open.

Contact Released → Channel Closed.

LED Indicators:

Red LED and keys: Status indicator.

Green LED (flicker): Indicates the device application layer is working properly.

• Additional Features:

  • Supports physical address allocation.
